Features







  • 1、High performance folder gluer with good price ratio.
  • 2、Excellent balance between stability and flexibility.
  • 3、Grinding ,counting and other functions are readily availabl







Technical indicators



Line speed

0—220m/min adjustable



Usage paper

210-600g/m²paperboard
ZH-600C requires less than 500g



Box forming

One side gluing or two side gluing



Paper Feeding

Automatic continuous feeding



Glue type

Gold glue



Power

ZH-600:2.2kw 220V

ZH-400C:2.2kw 220V

ZH-700:2.2kw 220V

ZH-800:3kw 220V

Weight

1000KGS

1000KGS

1000KGS

1500KGS

Dimension

6*1.3*1.3

6*1.3*1.3

6*1.4*1.3

8*1.5*1.3

Package dimensions

6.5m³1060/1204kg

6.5m³1050/1194kg

6.83m³ 1070/1220kg

9.29m³1305/1519kg

Feeder

2700*1100*1235=3.67m³ 680/764kg

2700*1100*1235=3.67m³ 670/754kg

2700*1200*1235=4m³  690/780kg

3380*1300*1235=5.43m³  830/932kg

Conveyor

2660*950*1120=2.83m³ 380/440kg

2660*950*1120=2.83m³ 380/440kg

2660*950*1120=2.83m³ 380/440kg

3660*950*1110=3.86m³  475/587kg


Technical parameters Unit: mm



Type

Box type

A MM

B MM

C Minimum MM

D Minimum MM

ZH-600

Straight line box

110-600

60-500

50

8

ZH-400C

Straight line box

65-400

60-400

30

8

ZH-700

Straight line box

110-700

60-500

50

10

ZH-800

Straight line box

130-800

60-600

60

12
