PRY-400PBF Automatic Punching Forming Single Spiral and Binding Machine

description1

Zipper closure 1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout

Features

Automatic Punching, Forming Single Spiral and Binding Machine,was researched and developed for the first time in China.
The machine has above eight items of patent for invention,which can improve the efficiency above 60%,it can produce the product at high speed, such as notebook, instruction book and so on.The machine can automatic feed the book, automatic punch one book several times, automatic adjust in hole,automatic form the spiral, automatic receive the book.

1,The machine only need one general man to operate.
3,It just need one minute to change the mould size.
2, High quality of punch mould, it can punch at most 3-6mm,which can add the oil automatic.One mould has two sides with two sizes of the hole,which makes the mould can be used for 3-5times of life than the normal mould.
4,The machine can positioning the hole automatically.
5,Automatic remind the malfunction.

Specifications

Model	PRY-400PBF
Wook speed	800-1800books/hours
Thickness of punch for one time	1-6mm
Max punching thickness	13mm(Special product:16mm)
Max punching times for one book	5times
Max book size	400mm(bind side)*420mm
Min book size	100mm(bind side)*140m
Max book size for feed belt	400*400mm
Size of spiral	1/4"-5/8"
pitch	4:1,3:1,6mm,8mm
Size of book for binding	100-400mm
Air compressor (customer provide)	3kw
Machine Dimension(LWH)	400025001600mm
Power Supply	220V /50HZ/60HZ/6KW
Air pressure	7-8 bar
Weight	1250kg
