PRY-QZX-1370M Programmed Control Automatic A4 Paper Cutting Machine

PRY-QZX-1370M Programmed Control Automatic A4 Paper Cutting Machine

description1

Zipper closure 1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout

PRY-QZX-1370M Programmed Control Automatic A4 Paper Cutting Machine

PRY-QZX-1370M Paper Cutting Machine

Features

1.High quality casting part made by resin bonded sand way.
2.Chrome-plated slot-less working table installed with double imported linear guide and air cushion.
3.Mechanical assistance device for knife replacement
4.Overload protection safety device
5.Infrared photoelectric protection device
6.Fluorescent lamp and cutting line indicator
7.Ejective device
8.Use imported components in Hydraulic system like Atos and Hassan
9.Use imported electronic units like SIEMENS,TOSHIBA,ORMON,LG
10.PLC control
11.Use imported Mechanic components like NSK Bearing
12.Imported Motor and motor made in china is optional

Technical Parameters

PRY-QZX-1370M Paper Cutting Machine
Model	920	1150	1300	1370
The Code Of Way Of Transmission	M	M	M	M
Cutting Width	940mm	1150mm	1300mm	1370mm
Cutting Length	940mm	1150mm	1300mm	1370mm
Cutting Height	120mm	160mm	130mm	160mm
Front Table Length	610mm	700mm	700mm	700mm
Front Table Height	930mm	930mm	930mm	930mm
Power Consumption Of Main Motor	3kw	5.5kw	4kw	5.5kw
Max. Clamping Pressure	3500dan	5000dan	5000dan	5000dan
Cutting Speed	45times/min	45times/min	45times/min	45times/min
Net Weight	2300kg	3800kg	3500kg	4500kg
Gross Weight	2500kg	4000kg	3700kg	4700kg
Overall Dimension	2.3×2.1×1.5m	2.5×2.7×1.6m	2.7×2.9×1.6m	2.8×3.2×1.7m
Packing Size	2.3×1.42×1.9m	2.65×1.62×1.9m	2.85×1.42×1.9m	2.85×1.62×2m

Q1.Are you a manufacturer or a trading company?

A:Our shanghai office is mainly doing export.We have our own factory in Wenzhou,Zhejiang Province.

Q2.What is the machine warranty?

A:One year.After the warranty,we still provide technical support to buyer at low cost.

Q3.What is the production time while placing order?

A:Normally about 10-20 days.

Q4.What is the delivery time?

A:15-30days after deposit.

Q5.Can your company handle shipping for customers?

A:Yes,just give us destination sea port or container yard.

Q6.Does the packing strong?

A:Yes.Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road transportation and various types of weather conditions.A full set of maintenance and operation manuals is included.

Q7.How about the machine installation and training?

A:1)We provide training in our factory for free;2)We can send technicians (engineers) to your factory for installation and training.You shall pay the round trip air fare and accommodations,plus each technician charges USD100/per day.

Q8.Do you have machines in stock?

A:For standard model,we have a large quantity in stock.For special model,we need 20-30 days to produce it for you.

Q9.How can you assure the machines’ quality?

A:Each machine will be test running at least 24 hours before delivery to assure the quality.And during the warranty,we will give spare parts for free if machine has any problem.

Q10.Do you inspect machines or test running before packing?

A:Of course we do.We have QC department to debug the machine before packing.If you want to use specific material to do the test running,you need to pay for the cost of the material.

Q11.What’s the payment term?

A:T/T 30% in advance,the balance shall be paid before delivery.We also accept payment by West Union or L/C at sight.

Q12.Do you accept factory visiting?

A:Warmly welcome for your visiting.

Q13.How many years are you in printing field?

A:The Shanghai company since in 2008,the factory is more than 25years.

Q14.How many clients do you have?

A:We have sold our machines to about 60 countries.We have agents in South Africa,Morocco and Italy.
