This machine is with 7 inch computer and the computer have 30 groups program and each program has 126 cutting capacity. The paper pusher is driven by LG converter and the speed of paper pusher can reach 10 meters per minute. The clamp is driven by hydraulic system and the clamp pressing pressure can be adjusted according to different type of paper. We use SIEMENS AC contactor, Toshiba Bridge Rectifier, Omron PLC, Schneider Travel Switch and LG Air Switch. This machine is combined with program function and at price level of digital display paper cutting machine. It is very suitable for small and medium scale printing and packing enterprise. The password can be set in advance. When this machine is used for some time, the computer will be locked and after final customer clear all payment then clear password. It can lower the reseller’ business risk

Feature

1.High quality casting part made by resin bonded sand way.

2.Chrome-plated slot-less working table installed with double imported linear guide and air cushion.

4.Overload protection safety device

5.Infrared photoelectric protection device

6.Knife cutting only operated by pressing two buttons at same time

7.Fluorescent lamp and cutting line indicator

8.Elective device for knife bar

9.Use imported components in Hydraulic system

10.Use imported electronic units like Siemens, TOSHIBA, ORMON, LG, Schneider and Fotek

11.ORMON PLC control

12.Driven by LG converter, the maximum speed of the back gauge is 10 m/min

13.Use imported Mechanic components like NSK Bearing

14.Single Hydraulic

15.With Germany Brand IKS Blade

 Technical parameters

Spare parts (Free)
