H5010L Hydraulic Variable Frequency Microcomputer Program Control Paper Cutter Machine
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
H5010L Hydraulic Variable Frequency Microcomputer Program Control Paper Cutter Machine
H5010L Hydraulic Paper Cutter
Technical Parameters
|
H5010L Hydraulic Paper Cutter
|
|
|
Max. Cutting Size
|
500*500 mm
|
|
Max. Cutting Thickness
|
100 mm
|
|
Min. Cutting Size
|
30 mm
|
|
Cutting Accuracy
|
±0.2 mm
|
|
Ball Table
|
√
|
|
Press Way
|
hydraulic
|
|
press way
|
|
|
Cutting Way
|
hydraulic
|
|
Display
|
7" touch screen
|
|
Program
|
√
|
|
Arithmetic
|
√
|
|
Push Motor
|
step motor
|
|
Frequency Conversion Motor
|
√
|
|
Power
|
220V(110V) ±10% , 50Hz(60Hz) , 3200W
|
|
Side Table
|
optional
|
|
Machine Size
|
1440*930*1165 mm
|
|
Net Weight
|
about 380kg
|
Configuration
Infrared safety protection design
Man-machine interface design,100 groups * 96 cuts program.
Back platform without groove design, overhanging ball screw push paper more stable
Patent for oblique cutting paper,cutting more easliy,suitable for thick paper cutting.
Thickened knife holder,strong and durable,quick change of knife strip
Higher speed cut paper with non-noise.
Stainless steel floating ball operation table, easy feeding the paper
Push book platform can be folded,covenient transportation.
Mechanical foot,cut riding nail book pre-alignment more convenient,higher precision
Dual hydraulic power control system,Paper pressure external regulating mechanisem.
