PRY-1080 Automatic Paper Board Stripping and Blanking Machine
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
PRY-1080 Automatic Paper Board Stripping and Blanking Machine
PRY-1080 Stripping and Blanking Machine
Features
* Large torque,fast starting,fast braking,fast reversing,precise pressure stroke control,and can work stably in harsh environments of high and low temperatures.It is safer and more stable than ordinary hydraulic systems.
* Compared with ordinary hydraulic systems,it saves 70% energy.
* It is 1/10 of the noise of ordinary hydraulic systems.
* It can continuously maintain pressure with infinite speed regulation,and the oil temperature is 1/3 of that of ordinary hydraulic stations,which prolongs the service life of the hydraulic system and is simple to maintain.
* High-density honeycomb panels can be equipped with φ 5/3 φ stripping pin to achieve full page stripping.The upper and lower honeycomb panels are engraved with scales for fast and accurate alignment.
Technical Parameters
|
Model
|
PRY-1080
|
|
Max. Paper Size
|
1080 * 780 mm
|
|
Min. Paper Size
|
400 * 200 mm
|
|
Max. Blanking Size
|
1030 * 730 mm
|
|
Min. Blanking Size
|
40 * 40 mm
|
|
Stripping Height
|
40 ~ 120 mm
|
|
Weight
|
3.5 t
|
|
Voltage
|
380 V
|
|
Power
|
8 kw
|
|
Blanking Speed
|
1 ~ 2 times/min
|
|
Net Weight
|
3500 kg
|
|
Machine Size
|
2000 * 1700 * 1950 mm
|
|
Machine Packing Dimension
|
2180 * 1870 * 2240 mm
|
Applications
