PRY-68 Automatic Single and Double Head Paper Board Stripping Machine
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
PRY-68 Automatic Single and Double Head Paper Board Stripping Machine
PRY-68 Automatic Single Head Stripping Machine
Features
Automatic stripping machine is designed and manufactured by our company in order to solve the problem of difficult talking out finished products by workers after die cutting cardboard.
After die cutting,use the machine to stripping automatically which is more convenient for workers to take out the finished products,high production,less cost and high efficient for customers.
Use the computerized PLC touch screen to adjust the data which is more convenient users, the main movement is combined by the hydraulic system and ball screw driven by servo motor which has low failure rate and more agile.
Technical Parameters
|
Model
|
PRY-68
|
PRY-ST68 |
|
Max. Stripping Area
|
680 * 450 mm
|
680 * 450 mm |
|
Mini. Stripping Area
|
450 * 320 mm
|
450 * 320 mm |
|
Max. Stripping Finished Product Size
|
220 * 220 mm
|
220 * 220 mm |
|
Mini. Stripping Finishes Product Size
|
30 * 30 mm
|
30 * 30 mm |
|
Stripping Height
|
40 ~ 120 mm
|
40 ~ 120 mm |
|
Stripping Speed
|
15 ~ 20 time/min
|
15 ~ 20 time/min |
|
Main Power
|
4 kw
|
4 kw |
|
Voltage
|
380V / 50HZ
|
380V / 50HZ |
|
Wire Specification
|
2.5 mm
|
2.5 mm |
|
Machine Weight
|
1500 kg
|
2000 kg |
|
Overall Dimension
|
2210 * 1600 * 1900 mm
|
2710 * 1600 * 1900 mm |
|
Packing Size
|
2510 * 1900 * 2050 mm
|
3010 * 1900 * 2050 mm |
Configuration
Excellent Hydraulic System
Semi-automatic PET bottle blowing machine bottle making machine bottle moulding machine PET bottle making machine is suitable for producing PET plastic containers and bottles in all shapes.
Double Safe Protection
Protection 1:Mechanical safe protection
Protection 2: High density safe light curtain
Solid Structure and Bear High Pressure
The new generation of blanking machine adopts a double cross beam structure.This structure is much more solid and it won't get crushed due to high pressure (especially for big models)
Double Servo,Ball-screw and LM Rail Drive Systems
The ball screw is driven by double servo to ensure the high product precision by using the Ball-Screw and LM Rail Drive Systems, blanking precision with smooth and quiet operation is realized.
New Structure
-Mirror polishing platform for wear resist and dirty proof,this can ensure the bottom paper won’t be scratched or get damaged while dragged on platform.
-No blanking tools is needed,two procedures will be saved.
-No blanking tools is needed,two procedures will be saved.
Material Movement System
After the blanking material has been picked up,the sheets automatically slide into place,and blanking is performed efficiently.
Arrange Pins to the Proper Shape
By simply arranging the pins,the blanking machine can blank a variety of product shapes and sizes.
Precise Arranging Pins Loader
The high density stripping pin loader is made by CNC processing center.Reasonable and compact design makes the stripping pin changing jobs are easy and fast.High precision and no need to change blanking tools.
Applications
It is suitable for automatic taking out the products like cloths label,card,medicine boxes,cigarette boxes,small toy boxes,etc.
